DURApulse GS3
AC Drives
DURApulse GS3 builds on the GS series
The DURApulse GS3 series builds on the simplicity and flexibility of the GS1 and GS2 series, incorporating feedback from our customers and extensive research and testing in our own drives lab. While the GS1 offers simple Volts per Hertz control, and the GS2 adds PID functionality and dynamic braking, DURApulse GS3 offers sensorless vector control and autotuning, as well as optional encoder feedback for enhanced speed control. DURApulse GS3 configuration settings are a superset of the GS series, so programming for the same parameters is identical across all series.
- 1 hp to 3 hp, 230VAC (single/three-phase input)
- 5 hp to 50 hp, 230VAC (three-phase input)
- 1 hp to 100 hp, 460 VAC (three-phase input)
Features
- Simple Volts/Hertz control
- Sensorless vector control with autotune
-
Sensorless vector control with optional
encoder feedback card, for tighter speed
control - Variable carrier frequency, depending on model
- IGBT technology
- 150% starting torque
- 150% rated current for one minute
-
Internal dynamic braking circuit for models
under 20 hp - Programmable jog speed
-
Removable smart keypad with parameter
upload/download - Easy-to-understand parameter text labels
-
HIM keypad with memory to store up to four
programs of any DURApulse drive - Three analog inputs and one analog output
- Eleven digital inputs
-
Four programmable outputs: Three digital
and one relay - One digital frequency pulse output
- RS-485 Modbus communications
- Ethernet communication optional
- UL/CE listed
-
Optional software package with full
programmability, trending and application
setup
Sensorless Vector Technology up to 100hp
DURApulse GS3 AC Inverters
| HP | PART NUMBER | OUTPUT AMPS | PRICE | PART NUMBER | OUTPUT AMPS | PRICE |
|---|---|---|---|---|---|---|
| 1.0 | GS3-21P0 | 5 | $271.00 | GS3-41P0 | 2.7 | $370.00 |
| 2.0 | GS3-22P0 | 7 | $312.00 | GS3-42P0 | 4.2 | $394.00 |
| 3.0 | GS3-23P0 | 11 | $379.00 | GS3-43P0 | 5.5 | $424.00 |
| 5.0 | GS3-25P0 | 17 | $429.00 | GS3-45P0 | 8.5 | $481.00 |
| 7.5 | GS3-27P5 | 25 | $611.00 | GS3-47P5 | 13 | $652.00 |
| 10 | GS3-2010 | 33 | $752.00 | GS3-4010 | 18 | $835.00 |
| 15 | GS3-2015 | 49 | $994.00 | GS3-4015 | 24 | $1,048.00 |
| 20 | GS3-2020 | 65 | $1,259.00 | GS3-4020 | 32 | $1,295.00 |
| 25 | GS3-2025 | 75 | $1,457.00 | GS3-4025 | 38 | $1,531.00 |
| 30 | GS3-2030 | 90 | $1,673.00 | GS3-4030 | 45 | $1,744.00 |
| 40 | GS3-2040 | 120 | $2,413.00 | GS3-4040 | 60 | $2,244.00 |
| 50 | GS3-2050 | 145 | $2,965.00 | GS3-4050 | 73 | $2,702.00 |
| 60 | n/a | n/a | n/a | GS3-4060 | 91 | $3,079.00 |
| 75 | n/a | n/a | n/a | GS3-4075 | 110 | $3,439.00 |
| 100 | n/a | n/a | n/a | GS3-4100 | 150 | $4,005.00 |
Accessories
- AC line reactors
- EMI filters
- Braking resistors
- Fuse kits and replacement fuses
- RF filter
- GS3-FB feedback card
- Ethernet interface
- GSoft drive configuration software
- Replacement keypads
- Remote panel adapter
- Keypad cables in 1, 3 and 5 meter lengths
- Four and eight-port communication boards
The DURApulse GS3 Digital Keypad
The GS3 digital keypad includes a 2 line x 16 character LCD display, 5 status LED Indicators, and 9 function keys. The diagram above shows all of the features of the digital keypad. The standard smart keypad (aka HIM or Human Interface Module) is designed with defaults for the North American customer and allows you to configure the drive, set the speed, start and stop the drive, and monitor critical parameters for your application. In addition, this keypad has internal memory that allows four complete programs to be stored and transferred to any DURApulse GS3 drive.
LCD Display
LCD display for real language programming. No need to have a manual to understand parameter configuration.
