GS1 AC Minidrives

• 1/4 and 1/2 hp, 115 VAC (single-phase input)
• 1/4, 1/2 and 1 hp, 230 VAC (single/three-phase input)
• 2 hp, 230 VAC (three-phase input)

Features

• Simple Volts/Hertz control
• Pulse Width Modulation(PWM)
• 3 - 10 kHz carrier frequency
• IGBT technology
• 130% starting torque at 5 Hz
• 130% rated current for 1 minute
• Electronic overload protection and stall prevention
• Adjustable accel and decel ramps
• S-curve settings for acceleration and deceleration
• Automatic torque and slip compensation
• DC braking
• Three skip frequencies
• Trip history
• Integral keypad and speed potentiometer
• Programmable jog speed
• Three programmable preset speeds
• Four programmable digital inputs, one programmable relay output
• Programmable analog input
• RS-485 Modbus communications up to 19.2K
• Optional Ethernet communications
• UL/CUL listed; CE
